Wood Batwing BW20.51QW Flex Wing Slasher

BW20.51QW Batwing™ Slasher

The Woods Equipment BW20.51QW Batwing™ Slasher is a standard-duty flex wing slasher. It has a 6.3m (20’) cut and has a cutting capacity of 50mm diameter material. The splitter gearbox is 250hp and the spindle gearboxes are 150hp. The BW20.51QW has a 50mm output shaft. Wings can operate at 90° up and 22° down. Wings can be operated in a vertical position allowing for slashing over banks.



  • Extra heavy output shaft allows the operator to cut heavier material
  • PTO Assist Lift System takes the weight off the shaft for the ease of hooking up the PTO shaft by the operator.
  • Independent suspension in the wheels allows floatation for a smoother ride, less vibration on slasher and a more precise cut.
  • The 25.5 inch new foam filled 20ply tyres will prevent any tyre punctures
  • Clean line top prevents the build up of trash on the top of the slasher for easy cleaning
  • Quality inputs, Quality product: made in the USA with American steel
  • Highest OH&S rated slashers: change blades from above the machine
  • Reduce downtime: Quick Change Blade System – change blades within minutes
  • Increased durability: 38mm (1.5”) blade pin is 4x stronger than the standard 19mm (3/4”) bolt on other slashers
  • Protect gearbox: stump jumping disc standard so blades can do a 360° rotation to minimise impact
  • Superior pasture management: does not leave a windrow, efficient distribution of material
  • Unrivaled 10 year gearbox warranty

Share:

Share on facebook
Share on twitter
Share on email

Additional information

Tractor PTO Horsepower (hp)

70hp – 180hp

Gearbox Horsepower (hp)

250hp Splitter, 150hp Spindle

Category

Standard

Cutting Width

6.3m (20ft)

Cutting Capacity

50mm

Cutting Height Range

50mm – 380mm

Transport Width

3.05m

'Quick Change' Blade Pins

Yes

Deck Design

Smooth sloped 3.5mm deck

PTO Drive

Heavy wide-angle input PTO drive

Deck Drives

Series 4 deck drives with 2 plate slip clutches

Wing Operating Range

Floating linkage on wing lift cylinders 90° up / 22° down

Skids

Full length replaceable “bolt on” formed side skids on wings

Shielding

Front and rear chain shielding on wings and centre section

Wing Hinge Pin

25mm full length

Stump Jumper

Yes

Blade Change

Access window on top of deck for easy blade change – exclusive feature

Blade Size

12.7mm x 101.6mm

Hitch

Swivel Clevis Hitch

Baffled Deck

Fully Baffled Deck

Centre Spring

No

Axle Arms

Spring loaded axle arms

Tip Speed

16,300fpm blade tip speed for 1000rpm PTO

Tyres

6x 25.5 x 8-14 foam filled severe duty ag 20 ply tyres

Warranty

10 year limited gearbox warranty; 2 year deck warranty

Options

Side Throw, Walking Tandem Beams, Dual Wheels on Wings

Description

Woods BW20.51QW Batwing Flex Wing Slasher

The Woods BW20.51QW 20ft Batwing Flex Wing Slasher Series range have a standard duty, heavy duty and extreme heavy duty series for tractors with a maximum PTO horsepower of 180hp. The cutting capacity ranges from 70mm diameter material to 100mm diameter material. The flex wing operating range is 90° up and 22° down. The flex wings can be operated in the vertical position allowing for slashing over banks. The extra heavy output shaft allows the operator to cut heavier material.

The PTO Assist Lift System takes the weight off the shaft for the ease of hooking up the PTO shaft by the operator. The independent suspension in the wheels allows floatation for a smoother ride, less vibration on slasher and a more precise cut. The 25.5 inch new foam filled 20ply tyres will prevent any tyre punctures. The clean line top on these flex wings prevents the build up of trash in the top of the slasher for easy cleaning.



  • Extra heavy output shaft allows the operator to cut heavier material
  • PTO Assist Lift System takes the weight off the shaft for the ease of hooking up the PTO shaft by the operator.
  • Independent suspension in the wheels allows floatation for a smoother ride, less vibration on slasher and a more precise cut.
  • The 25.5 inch new foam filled 20ply tyres will prevent any tyre punctures
  • Clean line top prevents the build up of trash on the top of the flex wing slasher for easy cleaning
  • Quality inputs, Quality product: made in the USA with American steel
  • Highest OH&S rated slashers: change blades from above the machine
  • Reduce downtime: Quick Change Blade System – change blades within minutes
  • Increased durability: 38mm (1.5”) blade pin is 4x stronger than the standard 19mm (3/4”) bolt on other slashers
  • Protect gearbox: stump jumping disc standard so blades can do a 360 degree rotation to minimise impact
  • Superior pasture management: does not leave a windrow, efficient distribution of material
  • Unrivalled 6 year gearbox warranty



Woods Exclusive Features Woods Exclusive Benefits
Made in USA with American Steel Quality inputs, quality product, designed and manufactured to last
Change blades from above slasher Highest OH&S rated slashers – greater value for money and reduced risk assessments
Quick Change Blades System Change blade within minutes and reduce the cost of downtime. Change blades roadside with light hand tools
4x stronger blade pin 38mm (1.5”) compared to 19mm (3/4”) bolt on other slashers Thinner bolts will wear quickly increasing chances of throwing a blade
Greaseable blade pin Ensure long life out of blade set reducing running costs
Built on complete subframe Increased structural integrity – stress points on frame not on skin. Optimal for efficient cut
Stump jumping disc Blades do a full 360° rotation minimising impact and protecting gearbox when slashing
Does not leave a windrow Efficient distribution of material, reduced risk of personnel and machinery
6 year gearbox warranty Confidence in design and function of gearbox for reliable slasher



SAFETY FIRST



OH&S Features unique to Woods slashers
Change blades from above the machine: no risk to operators or maintenance crews of having to get under slasher to change the blades. Slasher does not need to be on stands
Quick Change Blade System removes labour and material to change blades: only light hand tools required to change blades. No oxy or grinding risk
Will not leave a windrow: superior material discharge management as material will be spread evenly across the back of the slasher limiting risk to plant and personnel
38mm blade pin: is 4x stronger than the standard 3/4” bolt on standard slasher. A 3/4” bolt is more likely to wear through and throw blades
Tip Speed is not excessive: Woods tip speed is efficient for design of slasher. Excessive tip speed is not tolerant to hitting objects increasing chances of breaking/throwing blades



EFFICIENCY



Operating and R&M Cost Efficiency
Full structural sub frame increases integrity of slasher making it more durable than other slashers and fitting for our Australian conditions
Machined gearbox hubs and tight tolerance steel shield will prevent any material affecting lower gearbox seal ensuring long life out of gearbox with no oil leaks
Driveline hanger will prevent dirt and water affecting shaft when removed from tractor
38mm blade pin is 4x stronger than standard blade bolt so is slower wearing than others
Quick change blade pin system allows operators to change blades within 5 minutes with light hand tools. Can be completed roadside reducing downtime of machines
Greaseable blade pins ensure long life of blades and pins lowering R&M costs
Stump jumper allows for less shocks to gearbox and blades can spin 360° upon impact compare to a beam where large shocks emitted to gearbox and blades can become wedged in beam
Large deck clearance allows for large volume of material to be cut without choking and uses less HP and fuel





Get in touch with us to find out more about our Woods BW20.51QW 20ft Heavy Duty Batwing Slasher.
